For friction drilling, more machines are versatile than you might think. Whether you’re using a CNC machine, tube laser, or pillar drill, there’s a good chance your current setup is already suitable for friction drilling, no need for major investments.
CNC machines are ideal for friction drilling. Most 3- and 4-axis machines from brands like Mazak, Haas or Trumpf easily meet the requirements in terms of RPM, power, and process control. You’ll just need the right Flowdrill toolholder, suited to your spindle and clamping system.
Frictiondrilling is possible on CNC machines, tube laser machines, and pillar drill machines. However, we do not recommend using a handheld drill for frictiondrilling. We offer specific toolholders for each type of machine. If you want to know whether your machine is suitable for frictiondrilling, or if you’re curious about what a new machine could do for you, feel free to contact us for more information.
Tube laser machines are ideal for friction drilling. If your machine can apply axial force and reach the required RPMs, friction drilling is absolutely possible. This enables chipless hole-and-thread creation directly on laser-cut tubes. You’ll just need the right Flowdrill toolholder, suited to your clamping system.
Manual and automatic pillar drills can be used for friction drilling, provided the machine is stable and powerfull enough. It’s one of the most cost-effective ways to introduce friction drilling into your workshop, especially for small batch production.
Friction drilling doesn’t require an expensive machine, but it does require the right conditions:
| Requirement | Minimum Spec |
|---|---|
| Spindle speed (RPM) | 2,000–3,500+ depending on diameter/material |
| Spindle power (kW) | 1.1 kW or higher |
| Axial force | 1,000–2,000 N depending on material |
| Machine rigidity | High, no vibration or play during drilling |
| Toolholding | Use a Flowdrill-specified toolholder |
| Material clamping | Secure clamping is essential |
Still not sure if your machine qualifies? We’re happy to help you evaluate your current setup.
Don’t assume friction drilling is only for high-end CNCs. If your machine has speed, power, and stability, it can probably do the job. With the right toolholder, you can friction drill with:
